Four Bolt Flanges

Bearings that are mounted within a flanged housing are used when the bearing mounting surface is perpendicular to a shaft axis. They are commonly available in two, three, or four-hole configurations. Four-bolt flanged ball bearing units have a square shape with 4 holes for mounting to accomodate higher loads than two-bolt flanges. As with our 2-Bolt Flanged Bearing Units, 3-Bolt Flanged Bearing Units and our Flangette Series, the 4-bolt flanged bearing units have bearings that can be moved and aligned to better accomodate long shafts.

Bearings Catalog

Check out our online product catalog with more than 10,000 products with full specifications & 3D CAD Models available for download - all free of charge!

View Catalog

Standard housings from AST Bearings include both cast iron and thermoplastic materials and come with built-in grease nibs.

Four Bolt Flanges - Standard and Thermoplastic Series - Inch and Metric

Inch Series - UCF-2E and UCF-G5PL Inch Series:
- Inch Dimensions
- 1/2" to 3-1/4" Shaft Diameters
- Cast Iron or Thermoplastic Housings
Metric Series - UCFL-2E, and UCFL-G5PL Metric Series:
- Metric Dimensions
- 12 mm to 85 mm Shaft Diameters
- Cast Iron or Thermoplastic Housings

Other types of 4-bolt flange ball bearings can be special ordered to meet your specific requirements. If you don't see it in our catalog, just ask us for it.

AST Bearings is proudly presenting our new certificates for both the NJ and CA locations: AST Bearings’ ISO 9001:2015 Certificates

To learn more about what the ISO 9001 standard is, the differences between the 2015 and 2008 versions, and how AST verifies customer satisfaction: Learn About AST Bearings’ certification to ISO 9001:2015

Need Assistance Selecting the Proper Four Bolt Flanges?

If you need help in selecting the best products for your particular application, please remember that design engineering and application assistance are available from AST as part of our value-added services designed to make your job easier.
